150kg per hour cream chocolate filled cereal puffed snacks processing line
core-filled snack uses wheat flour, bean powder, tuber crops material, vegetable powder as the raw material. Via the effect of extrusion machine, to produce multiple types, different shapes, crispy and tasty snack. Due to it is a profitable project with less investment, It won the clients trust and favor.
Using its twin-screw co-extrusion systems, the chocolate filled cereal snacks processing line manufactured by Jinan Sunrising Machinery Co.,Ltd. can produce many kinds and shapes of filled sweet and savory snacks such as pillow shape, tubes and sticks.
Filled savory snacks are an interesting variation because they combine two textures: a crispy outer biscuit and a soft filling. The filling provides the dominant flavor to the product, complemented by the taste of the biscuit.
Filled snacks can be made on the same production equipment as directly expanded snacks by adding the core filler machine and multifunctional shaper.
Flow chart of cream filled ceral puffed snacks processing line:
1. powder mixer
2. stainless steel screw conveyor
3. double screw extruder
4.core filler
5. multishaper
6. hoister
7. dryer
The heating source of the dryer can be chosen based on the resources at local. We have the coal, diesel, gas and electric type for your choice.
The temperature can be controlled by the electric control cabinet from 0 to 200 degrees. The inner part is stainless steel mesh belt. The drying time can be adjusted by speed based on different products. We can customized for you on the basis of the workshop size with different layers from 3 layers, 5 layers and 7 layers etc and the length can be 3m, 5m, 7m, 8m, 10m and 15m etc.
8.hoister
9. double roller flavor machine
The advantages of the core filled snacks production line:
1.Ingredient flexibility
Processing of a wide range of raw materials for both outside shells and fillings. Fillings may include sweet or savory flavors.
2.Production of various of traditional and innovative shapes shapes may be made at the same time(pillows, triangles, sticks, ovals, diamond-shaped, squares, peanuts, hearts and/or bars), sizes, colors and coatings .
3.PLC control of production to ensure optimized process parameters for each recipe.
Technical parameter of double screw extruder:
| New model Snack food extruder |
| model | SR-57 | SR-65 | SR-75 | SR-95 |
| main motor power(kw) | 30 | 37 | 90 | 132 |
| rotary cutter power(kw) | 2.2 | 2.2 | 2.2 | 2.2 |
| feeding power(kw) | 2.2 | 2.2 | 2.2 | 2.2 |
| oil pump power(kw) | 0.75 | 0.75 | 0.75 | 0.75 |
| heating power(kw) | 14 | 14 | 14 | 14 |
| capacity(kg/h) | 150 | 200 | 400 | 1000 |
| size(mm) | 2300*1000*1800 | 2600*1000*1800 | 5000*1100*2200 | 5500*1100*2200 |
